FEATURES:
Features: ATV*1 (IEC), AV in*1 (RCA3), USB*1, HDMI*1, PC*1, PC audio*1, earphone*1;
Analog TV system: PAL, SECAM, NTSC, PAL-M/N;
USB slot: support audio/image/video;
With HDMI function@1080p, 720p, refresh frequency is 50/60Hz;
Multi Languages
Speaker:3D 8Ω10W*2 , power consumption 12W;
Adapter power: 100-240V AC, 12V DC or direct 100-240V AC
Optional 1: 2*AV+Game;
Optional 2: digital TV ISDB-T, DVB-T/T2/S2/C, ATSC; Dolby Function
Support AOSP WEBOS VIDAA SYSTEM for Youtub Netflix.ANDROID11 2G+16G
- Product Detail
Model No. | K185E1 | Model No. | K185E1 |
Size & Aspect Ratio | 18.5"(16:9) | Size & Aspect Ratio | 18.5"(16:9) |
Panel | CMO/BOE/AUO/CSOT | Panel | CMO/BOE/AUO/CSOT |
Minimum order Qty (OEM) | 1x40"HQ | Minimum order Qty (OEM) | 1x40"HQ |
Loading Capacity 20"/40"/40"HQ | 1428pcs/3328pcs | Loading Capacity 20"/40"/40"HQ | 1428pcs/3328pcs |
Pixel Pitch | 0.1165(H) X 0.3495(V) | Pixel Pitch | 0.1165(H) X 0.3495(V) |
Active area | 409.8(H) X 230.4(V) | Active area | 409.8(H) X 230.4(V) |
Max. Color | 16.7M | Max. Color | 16.7M |
Resolution | 1366 x 768 | Resolution | 1366 x 768 |
Contrast Ratio | 2000:1 | Contrast Ratio | 2000:1 |
Brightness | 200cd/㎡ | Brightness | 200cd/㎡ |
View Angle(CR≥10) | 176°(H) X 176°(V) | View Angle(CR≥10) | 176°(H) X 176°(V) |
LED backlight life | 100,000hours | LED backlight life | 100,000hours |
Response Time(Typ) | 6.5ms | Response Time(Typ) | 6.5ms |
TV Standard & Set Up | TV Standard & Set Up | ||
Video System | PAL/SECAM/NTSC-3.58,NTSC-4.43,PAL-60 | Video System | PAL/SECAM/NTSC-3.58,NTSC-4.43,PAL-60 |
Sound System | BG, DK, I , MN | Sound System | BG, DK, I , MN |
Audio system | MTS, Spatial Stereo, Dynamic Bass | Audio system | MTS, Spatial Stereo, Dynamic Bass |
Sound output | 3W X2 | Sound output | 3W X2 |
STEREO SYSTEM | YES | STEREO SYSTEM | YES |
NICAM | YES | NICAM | YES |
Deinterlace / Comb filter | 3D | Deinterlace / Comb filter | 3D |
3D Video Noise Reduction | YES | 3D Video Noise Reduction | YES |
OSD LANGUAGE | Multi language English/French/German/Spanish/Italian/Dutch/Portuguese | OSD LANGUAGE | Multi language English/French/German/Spanish/Italian/Dutch/Portuguese |
Connectors | Connectors | ||
AV | x1 | AV | x1 |
YPbPr or YCbCr (COMPONENT) | x1 | YPbPr or YCbCr (COMPONENT) | x1 |
VGA | x1 | VGA | x1 |
HDMI | x1 | HDMI | x1 |
Headphone | x1 | Headphone | x1 |
USB | x1 | USB | x1 |
tuner | x1 | tuner | x1 |
Coax digital output | Optional | Coax digital output | Optional |
CI | optional | CI | optional |
SCart | optional | SCart | optional |
