Feature:
1. 4K UHD can display a crystal clear image on screen.
2.Built-in WIFI modules on the Android motherboard and PC in the machine, which are convenient for users to perform wireless transmission and network operations through WIFI.
3.Support side-pull touch menu, support any channel writing, annotation, screenshot function; child lock function, button function can be shielded by setting, etc. Front-mounted expansion port:
4.Child Lock to avoid student malfunction and secure privacy. support to lock screen and power on/off button at the same time.
5.Front remote control window is convenient for users to use the remote control to operate, set and debug the machine. Front speaker sound, honeycomb sound hole.
Aluminum alloy outer frame, sandblasted anodized surface, iron shell back cover, active heat dissipation; ultra-narrow sandblasted face frame, ultra-narrow design, the face frame of the whole machine is only 26mm on one side.
6.20 Touch Points enable an interactive and collaborative atmosphere in classroom and meeting room.
7.3mm physical tempered anti-glare glass; strengthen the visual effect, improve the touch experience; standard 20-point touch, faster writing speed, the best writing experience.
- Product Detail
Touch Function | Touch Screen | Touch embedding |
Type | 10 points Infrared Touch in Android system / | |
W riting Style | Finger, stylus pen | |
Cursor Speed | 120 dots/s | |
Positioning Accuracy | More than 90% of the touch area is + 2mm | |
Touch resolution | 32767*32767 | |
Computer response | Automatic recognition of the system ≤ 15ms | |
Display | Computer response | Automatic recognition of the system ≤ 16ms |
Resolution | 3840*2160 | |
Viewing angles | 178(H),178(V) | |
Contrast ratio | 3000：1 | |
Brightness | 330 nits | |
Aspect Ratio | 16:9 | |
Network | WiFi | 2.4G |
3G/4G optional | extra cost | |
Ethernet RJ45 | yes | |
Buletooth | yes | |
Interface | Front Side Interface | TOUCH 1;;USB-C 1;USB 3;Front keys Power on/off; Signal source; Eco; Main page; Menu; Volume down; Volume up |
Side Interface | HDMI 2;TOUCH 1;USB2.0 1;USB3.0 2;USB-C 1 | |
Rear Interface | LAN IN 1;LAN OUT 1;RS232 1;HDMI OUT 1;SPDIF OUT 1;YPBPR 1;AV IN 1;AV OUT 1;MIC 1;EARPHONE 1;AUDIO IN 1;VGA IN 1 | |
Media play | Video format | MPEG-1/2/4,AVS2 MP,H.264,H265,VP9 |
Audio Format | MP3,AAC,WMA,RM,FLAC | |
HD Video | 480i / 480p / 576i / 576p / 720p / 1080i / 1080p /2160p | |
Support function | Support one-key power on/off and one-key energy saving;writing function without PC;touch menu function, switching between each channel | |
Support web browsing;local and online HD video playback, support 1080P playback;local and online music playback; | ||
Support to browse pictures in various formats;the browsing and management of various files such as office;USB update software | ||
Support WIFI wireless Internet access function;wireless mirorring;Annotations Mobile phone, computer, tablets wireless screen sharing | ||
Anti-glare AR glass | Yes | |
Others | Power consumption | Max power consumption: ≤110W【OPS not included】;Standby : ≤0.5W |
Speaker | 2*10W | |
Temperature | -20 to 60degrees | |
Language | Multi-language | |
Adapter | Internal power board (AC100V-240V, 50/60Hz) | |
Accessories | User Manual*1, ;Warranty Card*1; Remote control*1;Stylus*2;1.8m power cord *1;108*10mm WIFI antenna*1;1.5m HDMI cable *1;1.5m USB touch cable *1;wall mount kit | |
